Uhf High Voltage Rf Connector

Uhf High Voltage Rf Connector Specification

Power Supply
Not Applicable (Passive component)

Components
Metal shell, Insulating Teflon/PTFE, center pin, threaded coupling nut

Features
High voltage tolerant, corrosion resistant, robust mechanical structure

Thermal Conductivity
High (Metal body ensures heat dissipation)

IP Rating
IP40

Usage
RF equipment, Antennas, High voltage circuits

Operating Temperature
-55C to +155C

Input
Coaxial cable termination

Response Time
Instant (Mechanical component)

Output
Coaxial cable termination

Power Source
Not Applicable (Passive hardware)

Interface
UHF (PL259) threaded coupling

Display Type
Not Applicable/None

Product Type
UHF High Voltage RF Connector

Application
High voltage RF circuit, transmitter, laboratory, communications

Rated Voltage
5 kV (kilovolt)

Supply Voltage
Up to 5 kV

Size
PL259 Standard

Dimension (L*W*H)
Approx. 35 mm x 17 mm x 17 mm

Function
High voltage RF transmission and connection

Color
Silver/Metallic

Weight
Approx. 35 grams

Capacity
Suitable for high voltage, high frequency

Current Rating
20 Amperes max

Thickness
Standard body shell ~1.5 mm

Frequency
DC to 300 MHz

Impedance
50 Ohms

Dielectric Withstanding Voltage
5000 V RMS

Contact Resistance
<1.5 m (milliohms)

VSWR
<1.2 up to 300 MHz

Contact Material
Brass, gold/nickel plated

Coupling Mechanism
Threaded

Mounting Type
Cable mount (solder/crimp)

Insulation Material
PTFE (Teflon)

Termination Style
Solder

Body Material
Brass or Zinc alloy

RoHS Compliance
Yes

Surface Finish
Polished/Nickel plated

About Uhf High Voltage Rf Connector

Order the distinguished UHF High Voltage RF Connector, a superlative choice engineered for pristine RF transmission. Featuring impeccable 50 Ohms impedance, robust brass or zinc alloy body, and a corrosion-resistant, polished or nickel-plated surface, it ensures premium performance. The PTFE insulation and gold/nickel-plated contacts support up to 5 kV, while the threaded coupling guarantees secure connections. Buy this top-tier connector for RF equipment, transmitters, high-voltage circuits, antennas, and laboratories. Designed for reliability, it offers low contact resistance, high current rating, and RoHS compliance for demanding professional environments in India.

Commercial Uses and Application Areas of UHF High Voltage RF Connector

The UHF High Voltage RF Connector is a distinguished solution for various commercial environments where dependable RF transmission is paramount. It is extensively used in laboratories, broadcasting, transmitter stations, telecommunications, and high-voltage RF circuits. Its robust structure and high-voltage tolerance make it ideal for RF equipment, antenna connections, and specialized industrial applications. Order this connector for pristine signal integrity in testing facilities, research institutes, communication networks, and engineering workshops across industries.

Domestic Market, Payment Terms, and Certifications Fast Delivery Assured

Our UHF High Voltage RF Connector is stocked ready for swift domestic distribution across Indias main commercial hubs and technical sectors. We accept flexible payment terms, and shipping is arranged through trusted freight partners to ensure timely delivery. All connectors are RoHS certified, meeting the highest industry standards for safety and environmental compliance. Buy with confidenceyour products will be delivered promptly and in pristine condition to your required location, whether you are a dealer, importer, or retailer.

FAQs of Uhf High Voltage Rf Connector:

Q: How is the UHF High Voltage RF Connector typically used in RF applications?

A: This connector is primarily used for high-voltage RF transmission in equipment such as transmitters, antennas, and laboratory setups. It serves as a reliable interface for coaxial cable terminations, ensuring minimal signal loss across a wide frequency range.

Q: What are the main benefits of its threaded coupling mechanism?

A: The threaded coupling mechanism guarantees a secure and stable connection, maintaining pristine contact integrity even in environments subject to mechanical vibrations or frequent reassembly.

Q: Where is the UHF High Voltage RF Connector most commonly installed?

A: It is most commonly installed in high-voltage RF circuits, laboratories, transmitter stations, communication hubs, and any technical facility requiring robust and durable RF connectivity.

Q: What certifications does this connector comply with?

A: It is RoHS compliant, which means it adheres to strict safety, health, and environmental standards, ensuring reliability and safety in high-voltage applications.

Q: How does the connector support heat dissipation and long-term durability?

A: Its metal body features high thermal conductivity, enabling efficient heat dissipation, which prolongs service life and ensures stable operation even at elevated currents and voltages.

Q: Can this connector be delivered across India, and what payment terms are available?

A: Yes, the UHF High Voltage RF Connector is stocked ready for delivery throughout India, with flexible payment options and fast shipping to meet business requirements.
