M12 8Pin Male Connector

M12 8Pin Male Connector Specification

Input
8Pin Male connection

Output
M12 interface

Interface
M12 8Pin Male

Operating Temperature
-25C to +85C

Components
Male Insert, Shell, Lock Nut

Usage
Industrial Automation, Sensor Connectivity

Features
Waterproof, Screw Locking, Vibration Resistant

IP Rating
IP67

Product Type
Round Circular Connector

Application
Sensors, Fieldbus, Industrial Equipment

Rated Voltage
60V AC/DC

Supply Voltage
Up to 60V

Size
M12 standard

Dimension (L*W*H)
As per M12 dimensions (approx. 49mm x 15mm x 15mm)

Function
Data and Signal Transmission

Color
Black (housing with metal nut)

Weight
Approx. 12g

Current Rating
4A max

Capacity
8 Pin

Number of Contacts
8 Contacts

Standard
IEC 61076-2-101

Contact Material
Copper Alloy with Gold Plating

Termination Style
Solder or Crimp

Insulation Material
PA66 (Polyamide)

Mounting Type
Panel Mount / Cable Mount

Shielding
360° EMI Shielding

Connector Gender
Male

Cable Diameter Range
4mm-8mm

About M12 8Pin Male Connector

In line with clients diverse requirements, we are involved in providing an optimum quality products.The provided product is carried out under the supervision of our experts.This product is made as per the requirements of our valuable clients within the scheduled time-frame.The offered product is highly acknowledged by our clients owing to its high reliability and cost effectiveness features.Further, the provided product is also made as per the clientsspecific needs with respect to their budgetary constraints

Versatile Industrial Connectivity

Engineered for modern automation, the M12 8Pin Male Connector delivers reliable performance in connecting sensors, fieldbus systems, and industrial control equipment. Its compatibility with both panel and cable mounting options streamlines integration, while adherence to IEC 61076-2-101 guarantees standardization across applications.

Superior Protection and Durability

With an IP67 waterproof rating, robust PA66 insulation, and 360 EMI shielding, this connector is built to withstand harsh industrial conditions. The screw locking system ensures secure vibration-resistant connections, protecting against external elements and electromagnetic interference.

Flexible Design for Easy Installation

Accommodating multiple termination stylessolder or crimpand cable diameters from 4mm to 8mm, the M12 8Pin Male Connector simplifies installation for both new setups and retrofits. Its compact M12 standard size and lightweight design make it suitable for tight spaces without compromising on performance.

FAQs of M12 8Pin Male Connector:

Q: How is the M12 8Pin Male Connector typically installed in industrial setups?

A: The connector supports both panel mount and cable mount installations, allowing flexibility in various industrial settings. For termination, you can choose between soldering or crimping, based on wiring preferences and environmental conditions.

Q: What are the primary applications for this M12 8Pin Male Connector?

A: It is mainly used in industrial automation environments for connecting sensors, fieldbus systems, and other industrial equipment that require secure and reliable data and signal transmission.

Q: When should I opt for the M12 8Pin Male Connector over other types?

A: Choose this connector when you need robust, waterproof (IP67), vibration-resistant connections for applications with stringent requirements for EMI shielding and standard compliance (IEC 61076-2-101), especially in environments with significant moisture or electromagnetic interference.

Q: Where can this connector be sourced in India?

A: The M12 8Pin Male Connector is readily available through dealers, distributors, exporters, fabricators, importers, manufacturers, producers, retailers, service providers, suppliers, traders, and wholesalers across India.

Q: What is the process for terminating cables with this connector?

A: Cables can be terminated using either solder or crimp techniques. Simply select the compatible cable (4mm to 8mm in diameter), strip the ends, and connect to the specified contact points, following either crimping or soldering methods as suited for your installation.

Q: How does this connector benefit industrial automation applications?

A: It offers secure and stable data transmission, enhanced environmental protection with its IP67 rating, superior EMI shielding, and easy, reliable screw locking. These features collectively ensure minimal downtime and reduced maintenance in critical automation systems.

Q: What makes the M12 8Pin Male Connector suitable for harsh industrial environments?

A: Its construction includes a corrosion-resistant copper alloy with gold plating for the contacts, robust PA66 housing, a metal nut, and full 360 EMI shielding, making it highly resistant to vibration, moisture, and electromagnetic disruptions.
