2.92FEMALE TO 2.92FEMALE ADAPTOR

2.92FEMALE TO 2.92FEMALE ADAPTOR Specification

Operating Temperature
-55C to +165C

Power Source
Passive

Input
2.92mm Female Connector

Output
2.92mm Female Connector

Features
Low VSWR, High precision, Rugged

Usage
Test and measurement applications, RF/microwave systems

Interface
2.92mm Female to 2.92mm Female

IP Rating
IP50

Components
Metal body, inner conductor, insulator

Product Type
Connector Adapter

Application
High-frequency signal transmission up to 40 GHz

Size
Standard 2.92mm dimensions

Dimension (L*W*H)
Approx. 20mm x 9mm x 9mm

Function
Connecting two 2.92mm female RF interfaces

Color
Silver

Weight
Approx. 8 g

Frequency
DC to 40 GHz

Contact Material
Gold plated beryllium copper

Mating Cycles
500 minimum

Impedance
50 Ohms

Insulation Material
PTFE

Maximum Power Handling
Up to 20 Watts (depends on frequency)

VSWR
<1.25 up to 40 GHz

Mounting Type
In-line

Return Loss
>20 dB up to 40 GHz

Finish
Satin/Nickel plating

Body Material
Stainless Steel

RoHS Compliant
Yes

Connector Type
2.92mm (K-type) Female

About 2.92FEMALE TO 2.92FEMALE ADAPTOR

Experience the unprecedented performance of our 2.92mm Female to 2.92mm Female Adaptornow at a reduced price! Engineered for high-frequency signal transmission up to 40 GHz, this gorgeous adaptor boasts first-rate impedance matching (50 Ohms), low VSWR (<1.25), and high return loss (>20 dB). The premium stainless steel construction with gold-plated beryllium copper contacts ensures rugged reliability and excellent conductivity. RoHS compliant and fitted with satin/nickel plating, this in-line adaptor is ideal for demanding RF/microwave systems. Try nowadd to cart and elevate your test and measurement setup!

Precision in Action: Application, Advantage & Features

The 2.92mm Female to 2.92mm Female Adaptor excels in critical application areas such as RF/microwave systems and test and measurement instrumentation. Its low VSWR and high return loss make it advantageous for precise signal integrity in high-frequency environments. Key features include a rugged stainless steel body, gold-plated contacts for optimum conductivity, and high mating cycle durability, making this adaptor a dependable component in demanding electronic setups.

Supply Ability, Sample Policies & Market Reach

Our supply chain is supported by reliable transport services, ensuring swift and safe transportation across the main domestic markets of India. We estimate prompt delivery times based on customer-specific order quantities. Sample policies are flexible, providing samples on request for evaluation. Whether for dealer, distributor, or direct use, our streamlined logistics and distribution ensure the highest accessibility and timely support across India.

FAQs of 2.92FEMALE TO 2.92FEMALE ADAPTOR:

Q: How does the 2.92mm female to 2.92mm female adaptor benefit high-frequency signal transmission?

A: This adaptor ensures minimal signal loss and distortion with a return loss greater than 20 dB and a VSWR less than 1.25 up to 40 GHz, delivering clear, high-quality transmission.

Q: What is the process for obtaining a sample of this adaptor?

A: You can request a sample through our flexible sample policy. Simply reach out to our sales team, and we will estimate delivery times based on your requirements and preferred transport services.

Q: Where can this adaptor be used effectively?

A: It is ideal for RF/microwave systems, test and measurement setups, and any application requiring reliable high-frequency connectivity up to 40 GHz.

Q: What advantages does the stainless steel body and gold-plated contact offer?

A: The stainless steel body provides robust durability, while the gold-plated beryllium copper contact ensures superior conductivity and corrosion resistance for long-lasting performance.
